Preface

With the evolution of time, technological progress and people demand for convenience have made the impact of communication technology on our lives inseparable, and also prompted the accelerated development of communication frequency to high-frequency band. The breakthrough of microwave high-frequency technology has facilitated the rapid development of wireless communication and brought about many important scientific and engineering applications. Due to its high-frequency characteristics, it has the advantages of strong penetration ability, fast transmission speed as well as high resolution, and plays an important role in modern technology.

< Extended reading: Microwave Technology Principles and Applications >

What is high frequency?

High frequency refers to electromagnetic wave frequencies that are higher than other specific frequency ranges, usually between MHz and GHz. The shorter wavelengths and higher energies of electromagnetic waves in this range are suitable for applications such as wireless communications, radar, and medical imaging. The development of high-frequency technology has led to many modern communications and technological innovations, enabling faster transmission of information, more efficient detection of objects, and more accurate diagnosis of diseases.

what is radio frequency?

Radio Frequency (RF) refers to a specific frequency range in the radio spectrum, and usually between 300 kHz and 300 GHz. RF waves are electromagnetic waves with high frequency and short wavelength, where wavelength and frequency band are two important concepts in describing electromagnetic waves. Simply put, wavelength is the distance from one full wave peak to the next, while frequency band refers to the electromagnetic wave within a specific wavelength range.

Since RF waves can penetrate through air and most materials, RF technology has been widely used in radio communication, radar, satellite communication, wireless LAN, Bluetooth, RFID, medical imaging and other fields.

< Extended reading: What is mmWave? Advantages, Disadvantages and Applications! >

What are the radio frequency bands?

Low Frequency

Electromagnetic waves of relatively long wavelengths, usually including radio waves, long waves and medium waves. These longer wavelengths are used in communications and radio, where low-frequency waves are often able to penetrate obstacles such as buildings and terrain, and perform better in long-distance communications.

Intermediate Frequency

Intermediate frequency (IF) is located between low frequency and high frequency, with relatively short wavelengths, usually including shortwave and ultra-shortwave bands. The characteristics of IF are that it can maintain a relatively stable transmission within a certain range in communication, and it also has a certain penetration capability.

High Frequency

High-frequency (HF) waves have relatively short wavelengths, including VHF (Very High Frequency), UHF (Ultra High Frequency) and microwave bands. These bands are commonly used in applications such as wireless communications, satellite communications, radar and microwave ovens. HF is characterized by fast transmission speeds, but has a lower penetration ability into obstacles and requires shorter transmission distances.

Applications of high frequency

High-frequency applications refer to a variety of areas where electronics and communications technologies are used in the higher frequency range. These areas often require the processing of high frequency signals and have high requirements for signal quality, transmission speed and accuracy. The following are a few common high-frequency application areas:

Radio communications

Wireless communication is a technology that uses radio waves to transmit information and has a wide range of applications.

In addition to common wireless communication applications such as Wi-Fi, Bluetooth, etc., there are other applications as follows:

1. Unmanned Aerial Vehicles (UAVs) and Remotely Controlled Aircraft (RCAs): Wireless communication technologies are used in UAVs and RCAs for remote control, data transfer, image transmission, etc., as well as to support autonomous flight and mission execution of UAVs.

2. Wireless Sensor Network (WSN): WSN combines wireless network technology, sensors, data loggers and information technology into a network for monitoring and collecting data from specific environments, such as temperature, humidity, light, etc., and transmitting the data to a central node for analysis and processing.

3. In-vehicle communication systems: In-vehicle communication technologies include in-vehicle telephones, in-vehicle entertainment systems, vehicle-to-infrastructure communications, etc., which provide wireless communication capabilities both inside and outside the vehicle.

Radar systems

Radar systems utilize high-frequency electromagnetic waves to detect and track the position, velocity, and other characteristics of a target object.

The following are the main applications of wireless communication in radar systems:

1. Transmitting and receiving signals: A radar system usually consists of a transmitter and a receiver, which transmit signals through wireless communication.

2. Signal Processing: The receiver of the radar system receives the signals reflected from the target object and analyzes them through signal processing to determine the characteristics of the target object, such as distance, speed, and orientation.

3. Echo Signal Decoding: Wireless communication is used in radar systems to decode and analyze echo signals to extract information about the target object. This includes analyzing the frequency, amplitude, and phase of the signal.

4. Data transmission: The radar system can use wireless communication to transmit data, such as the characteristics of the target object, identification codes and other information.

Medical applications

In healthcare applications, wireless communication covers a wide range of uses and facilitates effective healthcare delivery and patient care.

Here are some of the key applications:

1. Wireless medical devices: Many medical devices, such as wearable monitors, implantable devices and sensors, utilize wireless communication to transmit data wirelessly to healthcare professionals. For example, an electrocardiogram (ECG) monitor can continuously monitor a patient's heart activity and transmit the data to healthcare professionals in real time.

2. Remote patient monitoring: Remote patient monitoring systems enable healthcare professionals to remotely monitor patients' vital signs, medication adherence and overall health status. It is particularly useful for managing chronic diseases and providing timely intervention.

3. Hospital communication systems: Hospitals utilize wireless communication systems for internal communication among health-care workers, emergency responders and support staff. These systems include two-way radios, pagers and wireless communications equipment to ensure seamless coordination and rapid response to emergencies.

Recommendation for high frequency applications of coaxial connectors and cables

In RF propagation technology, the selection of coaxial connectors and coaxial test cables for each frequency range requires the following considerations:

< Extended reading: What are RF/Microwave Connectors? >

Good shielding properties

Coaxial test cable consists of inner conductor, insulating layer and outer conductor, which is usually wrapped by metal shielding; while coaxial connector structure design and material properties also have good shielding performance, which can effectively prevent external interference and signal leakage. High-frequency coaxial connectors and coaxial test cables from Huang Liang Technologies have good shielding properties, making them ideal for high-frequency applications, especially in environments where signal stability and transmission quality need to be ensured.

Low Transmission Loss

Huang Liang Technologies uses the fixed distance between the inner and outer conductors of the coaxial test cable and the protection of the outer shielding layer. In addition, with the coaxial connector, it is matched through insulating materials, surface treatment and structural optimization. All help to reduce the signal attenuation and energy loss, so that they can achieve lower transmission loss in high-frequency applications, and to ensure the electrical performance as well as stability of the transmission.

Wide frequency range

The coaxial connectors and adapters of Huang Liang Technologies have been able to support a wide range of frequencies and are suitable for many high frequency applications, including wireless communications, radar, satellite communications, etc.

Recommended Products

2.92mm PLUG to JACK Radius R/A Adapter

SMP ST. JACK TO JACK BULLET SPRING LOADED ADAPTER

IEEE Standard Radar Band Nomenclature:

IEEE Std. 521-2002, IEEE Standard Letter Designations for Radar-Frequency Bands

Conclusion

As high-frequency applications continue to evolve, related technologies are facing challenges, including signal degradation, transmission loss, and performance improvement. As a professional manufacturer of RF microwave connectors, Huang Liang Technology will overcome these challenges through faster, more flexible and reliable engineering solutions and provide customers with coaxial connectors and coaxial test cables for a wide range of frequencies (1GHz to 110GHz) with low loss and good shielding performance. If you would like to know more about our products, please feel free to contact us.
